7MBR75U4B120-50

Power Integrated Module, 1200 V, 1.0 mA, 275 W, 75 A, 1.20 μs

Rated 5 Rating 5 | reviews | Write a review

Price:: US $56.00~521.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $56.00~521.00

PartNumber:: 7MBR75U4B120-50

Brand:: Fuji Electric - FE | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Rita's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-08

From Other Seller

Part Number:7MBR75U4B120-50
US $56.00 - 521.00
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
TOP259EN

US $1.10 - 3.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 7MBR75U4B120-50 is a Power Integrated Module.

Parametrics

7MBR75U4B120-50 absolute maximum ratings: (1)Collector-Emitter voltage: 1200 V; (2)Gate-Emitter voltage: ±20 V; (3)Collector current: 75 A at Tc=25℃, 50 A at Tc=80℃; (4)Collector Power Dissipation: 275 W at 1 device; (5)Collector-Emitter voltage: 1200 V; (6)Gate-Emitter voltage: ±20 V; (7)Collector current: 35 A at Tc=25℃, 25 A at Tc=80℃; (8)Repetitive peak reverse Voltage (Diode): 1200 V.

Features

7MBR75U4B120-50 electrical characteristics: (1)Zero gate voltage Collector current: 1.0 mA at VGE = 0V, VCE = 1200V; (2)Gate-Emitter leakage current: 200 nA at VCE = 0V, VGE=±20V; (3)Gate-Emitter threshold voltage: 4.5 to 8.5 V at VCE = 20V, Ic = 75mA; (4)Input capacitance: 6 nF at VCE=10V,VGE=0V,f=1MHz; (5)Turn-on time: 1.20 μs at Vcc = 600V; (6)Turn-off time: 1.00 μs at Ic = 75A; (7)Forward on voltage: 2.45 V at VGE=0V, 2.10 V at IF = 75A.
