Product Summary

The FS225R17KE3/AGDR-71C is an IGBT module.

Parametrics

FS225R17KE3/AGDR-71C absolute maximum ratings: (1)collector-emitter voltage, VCES: 1700V; (2)DC-collector curretn, IC nom: 325A; IC: 340A; (3)repetitive peak collector curent, ICRM: 450A; (4)totla power dissipation, Ptot: 1400W; (5)gate-emitter peak votlage, VGES: +/-20V.

Features

FS225R17KE3/AGDR-71C features: (1)repetitive peak reverse, VRRM: 1700V; (2)DC forward current, IF: 225A; (3)repetitive peak forward current, IFRM: 450A; (4)I2t-value, I2t: 8300A2s.

Diagrams

FS225R17KE3/AGDR-71C circuit diagram
