MG300Q1US21

insulated gate bipolar transistor, 1200V, 300A, 2000W, high input impedance, high speed

Rated 5 Rating 5 | reviews | Write a review

Price:: US $68.00~103.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $68.00~103.00

PartNumber:: MG300Q1US21

Brand:: Toshiba Semiconductor - Toshiba | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Rita's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-28

From Other Seller

Part Number:MG300Q1US21
US $68.00 - 103.00
AT45DB161B-TI

US $0.90 - 2.00 / Piece
(0) Remove
SLA4060

US $0.80 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MG300Q1US21 is an insulated gate bipolar transistor. The applications of the device include GTR module, silicon N channel IGBT, high power switching applications and motor control applications.

Parametrics

MG300Q1US21 absolute maximum ratings: (1)collector-emitter voltage, VCES: 1200V; (2)gate-emitter voltage, VGES: ±20V; (3)collector current, DC, IC: 300A; 1ms, ICP: 600A; (4)forward current, DC, IF: 300A; 1ms, IFM: 600A; (5)collector power, PC: 2000W; (6)junction temperature, Tj: 150℃; (7)storage temperature range, Tstg: -40 to 125℃; (8)isolation voltage, Visol: 2500V.

Features

MG300Q1US21 features: (1)high input impedance; (2)high speed; (3)low saturation voltage; (4)enhancement mode; (5)the electrodes are isolated from case.
