1MBI600PX-140-03

IGBT module, 4100W, 1400V, 1600A, 1MBI600PX-140-03, Fuji Electric

Rated 5 Rating 5 | reviews | Write a review

Price:: US $126.00~150.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $126.00~150.00

PartNumber:: 1MBI600PX-140-03

Brand:: Fuji Electric - FE | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Rita's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-28

From Other Seller

Part Number:1MBI600PX-140-03
US $126.00 - 150.00
AT45DB161B-TI

US $0.90 - 2.00 / Piece
(0) Remove
RTL8102EL

US $1.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 1MBI600PX-140-03 is an IGBT module.

Parametrics

1MBI600PX-140-03 absolute maximum ratings: (1)collector-emitter voltage, VCES: 1400V; (2)gate-emitter voltage, VGES: ±20V; (3)collector current, continuous, IC: 800A at Tc=25℃; 600A at Tc=80℃; 1ms, IC pulse: 1600A at Tc=25℃; 1200A at Tc=80℃; -IC: 600A; 1ms, -IC pulse: 1200A; (4)max power dissipation, PC: 4100W; (5)operating temperature, Tj: 150℃storage temperature, Tstg: -40 to 125℃; (6)isolation voltage, Vis: AC 2500V.

Features

1MBI600PX-140-03 features: (1)zero gate voltage collector current, ICES: 2.0mA; (2)gate-emitter leakage current, IGES: ±0.5μA; (3)gate-emitter threshold voltage, VGE(th): 6.0 to 9.0V; 6.0V typ; (4)collector-emitter saturation voltage, VCE9sat): 3.2V max; 2.85V typ; (5)input capacitance, Cies: 60nF; (6)output capacitance, Coes: 9nF; (7)reverse transfer capacitance, Cres: 4nF.
